Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Flexible)
ü
Insulation : Electron Beam Cross linked
Polyolefin Class D (Thin Wall)
ü
Insulation Colour : As per ISO 19642-1
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) as per
Customer order
Siechem
Multi Core Unscreened, Flexible Class D (Thin) 1000V AC EV 150 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Over all Diameter
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
12.7
12.7
12.7
7.60
7.60
7.60
4.71
4.71
4.71
3.14
3.14
3.14
1.82
1.82
1.16
1.16
Min.
Max.
2C x 1.5
3C x 1.5
4C x 1.5
2C x 2.5
3C x 2.5
4C x 2.5
2C x 4
3C x 4
4C x 4
2C x 6
3C x 6
4C x 6
2C x 10
3C x 10
2C x 16
3C x 16
182
182
182
140
140
140
224
224
224
189
189
189
320
320
512
512
0.11
0.11
0.11
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.24
0.24
0.24
0.28
0.28
0.28
0.32
0.32
0.32
0.32
0.32
0.32
0.48
0.48
0.52
0.52
5.4
5.8
6.5
6.7
7.2
8.0
8.1
8.7
9.7
9.4
10.1
11.2
12.8
13.8
15.3
16.4
5.9
6.4
7.0
7.3
7.8
8.6
8.8
9.4
10.4
10.1
10.8
12.0
13.7
14.7
16.2
17.4
0
0
ü
Rated Temperature : - 40 C to +150 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5 Sqmm)
ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722,Generally
as per QC / T 1037-2016**
mm
0.6
0.6
0.6
0.6
0.7
0.7
0.7
0.7
0.8
0.7
0.8
0.8
0.8
0.9
0.9
0.9
Sheath
Thickness
(Nom.)
A9481302
A9481303
A9481304
A9481602
A9481603
A9481604
A9481902
A9481903
A9481904
A9482302
A9482303
A9482304
A9482702
A9482703
A9482802
A9482803
28
25
23
39
34
32
53
46
43
68
59
55
96
84
130
113
Note :
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 150 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A948
Catalogue
No
70
90
110
105
140
170
160
215
265
220
290
365
390
510
590
770
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
