Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Flexible)
ü
Insulation : Electron Beam Cross Linked
Polyolefin Class C (Thick Wall)
ü
Insulation Colour : As per ISO 19642-1
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) As Per
Customer Order
Siechem
Multi Core Unscreened, Flexible Class C (Thick) 1000V AC EV 125 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Over all Diameter
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
12.7
12.7
12.7
7.60
7.60
7.60
4.71
4.71
4.71
3.14
3.14
3.14
Min.
Max.
2C x 1.5
3C x 1.5
4C x 1.5
2C x 2.5
3C x 2.5
4C x 2.5
2C x 4
3C x 4
4C x 4
2C x 6
3C x 6
4C x 6
182
182
182
140
140
140
224
224
224
189
189
189
0.11
0.11
0.11
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.48
0.48
0.48
0.56
0.56
0.56
0.64
0.64
0.64
0.64
0.64
0.64
7.7
8.2
9.0
9.0
9.6
10.6
10.7
11.4
12.6
12.0
12.8
14.1
8.3
8.8
9.7
9.7
10.3
11.3
11.4
12.2
13.4
12.8
13.6
15.0
111
140
168
166
210
255
240
305
370
315
395
490
0
0
ü
Rated Temperature : - 40 C to +125 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5
Sq.mm)ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722, Generally
as per QC / T 1037-2016**
mm
1.1
1.2
1.2
1.2
1.3
1.3
1.3
1.4
1.4
1.4
1.4
1.5
Sheath
Thickness
(Nom.)
A9461302
A9461303
A9461304
A9461602
A9461603
A9461604
A9461902
A9461903
A9461904
A9462302
A9462303
A9462304
28
25
23
39
34
32
53
46
43
68
59
55
Note :
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 125 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A946
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
