Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Stranded)
ü
Insulation : Electron Beam Cross linked
Polyolefin Class C (Thin Wall)
ü
Insulation Colour : As per ISO 19642-1
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) As Per
Customer Order
Siechem
Multi Core Unscreened, Stranded Class C (Thin) 1000V AC EV 125 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Over all Diameter
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
12.7
12.7
12.7
7.60
7.60
7.60
4.71
4.71
4.71
3.14
3.14
3.14
1.82
1.82
1.16
1.16
Min.
Max.
2C x 1.5
3C x 1.5
4C x 1.5
2C x 2.5
3C x 2.5
4C x 2.5
2C x 4
3C x 4
4C x 4
2C x 6
3C x 6
4C x 6
2C x 10
3C x 10
2C x 16
3C x 16
19
19
19
37
37
37
56
56
56
84
84
84
144
144
228
228
0.33
0.33
0.33
0.30
0.30
0.30
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.24
0.24
0.24
0.28
0.28
0.28
0.32
0.32
0.32
0.32
0.32
0.32
0.48
0.48
0.52
0.52
5.4
5.8
6.5
6.7
7.2
8.0
8.1
8.7
9.7
9.4
10.1
11.2
12.8
13.8
15.3
16.4
5.9
6.4
7.0
7.3
7.8
8.6
8.8
9.4
10.4
10.1
10.8
12.0
13.7
14.7
16.2
17.4
66
80
101
100
130
160
150
200
245
210
280
345
365
480
560
730
0
0
ü
Rated Temperature : - 40 C to +125 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5 Sqmm)
ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722,Generally
as per QC / T 1037-2016**
mm
0.6
0.6
0.6
0.6
0.7
0.7
0.7
0.7
0.8
0.7
0.8
0.8
0.8
0.9
0.9
0.9
Sheath
Thickness
(Nom.)
A9451302
A9451303
A9451304
A9451602
A9451603
A9451604
A9451902
A9451903
A9451904
A9452302
A9452303
A9452304
A9452702
A9452703
A9452802
A9452803
28
25
23
39
34
32
53
46
43
68
59
55
96
84
130
113
Note :
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 125 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A945
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
