Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Stranded)
ü
Insulation : Electron Beam Cross linked
Polyolefin Class D (Thin Wall)
ü
Insulation Colour : As per ISO 19642-1
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) as per
Customer order
Siechem
Multi Core Unscreened, Stranded Class D (Thin) 1000V AC EV 150 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Over all Diameter
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
12.7
12.7
12.7
7.60
7.60
7.60
4.71
4.71
4.71
3.14
3.14
3.14
1.82
1.82
1.16
1.16
Min.
Max.
2C x 1.5
3C x 1.5
4C x 1.5
2C x 2.5
3C x 2.5
4C x 2.5
2C x 4
3C x 4
4C x 4
2C x 6
3C x 6
4C x 6
2C x 10
3C x 10
2C x 16
3C x 16
0.24
0.24
0.24
0.28
0.28
0.28
0.32
0.32
0.32
0.32
0.32
0.32
0.48
0.48
0.52
0.52
5.4
5.8
6.5
6.7
7.2
8.0
8.1
8.7
9.7
9.4
10.1
11.2
12.8
13.8
15.3
16.4
5.9
6.4
7.0
7.3
7.8
8.6
8.8
9.4
10.4
10.1
10.8
12.0
13.7
14.7
16.2
17.4
0
0
ü
Rated Temperature : - 40 C to +150 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5 Sqmm)
ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722,Generally
as per QC / T 1037-2016**
mm
0.6
0.6
0.6
0.6
0.7
0.7
0.7
0.7
0.8
0.7
0.8
0.8
0.8
0.9
0.9
0.9
Sheath
Thickness
(Nom.)
A9491302
A9491303
A9491304
A9491602
A9491603
A9491604
A9491902
A9491903
A9491904
A9492302
A9492303
A9492304
A9492702
A9492703
A9492802
A9492803
28
25
23
39
34
32
53
46
43
68
59
55
96
84
130
113
Note :
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 150 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A949
Catalogue
No
19
19
19
37
37
37
56
56
56
84
84
84
144
144
228
228
0.33
0.33
0.33
0.30
0.30
0.30
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
66
80
101
100
130
160
150
200
245
210
280
345
365
480
560
730
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
