Wires & Cables
Product Construction
Technical Data
0
0
ü
Rated Temperature : - 40 C to +150 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5
Sq.mm)ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-5, ISO 6722
, Generally
as per
QC / T 1037-2016 **
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Stranded)
ü
Insulation : Electron Beam Cross Linked
Polyolefin
Class D (Thick Wall)
ü
Insulation
Colour
: Orange (or) As Per
Customer Request
Siechem
Single Core, Stranded Class D (Thick) 1000V AC EV 150 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(mm)
(Max.)
Conductor Construction
Over all Diameter
(mm)
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
*
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
37.1
24.7
18.5
14.9
12.7
9.42
7.60
6.15
4.71
3.94
3.14
2.38
1.82
1.52
1.16
0.955
0.743
0.647
0.527
0.473
0.368
0.315
0.259
0.219
0.196
0.153
Min.
Max.
1C x 0.5
1C x 0.75
1C x 1
1C x 1.25
1C x 1.5
1C x 2
1C x 2.5
1C x 3
1C x 4
1C x 5
1C x 6
1C x 8
1C x 10
1C x 12
1C x 16
1C x 20
1C x 25
1C x 30
1C x 35
1C x 40
1C x 50
1C x 60
1C x 70
1C x 85
1C x 95
1C x 120
0.48
0.48
0.48
0.48
0.48
0..48
0.56
0.56
0.64
0.64
0.64
0.64
0.80
0.80
0.80
0.88
1.04
1.04
1.04
1.12
1.20
1.20
1.20
1.28
1.28
1.28
2.00
2.20
2.40
2.40
2.70
3.00
3.30
3.80
4.00
4.50
4.60
5.00
5.90
6.60
7.70
8.10
9.40
9.70
9.60
11.20
11.50
13.40
13.50
14.80
16.00
17.70
2.30
2.50
2.70
2.95
3.00
3.30
3.60
4.10
4.40
4.90
5.00
5.90
6.50
7.40
8.30
9.10
10.40
10.90
11.60
12.40
13.50
14.60
15.50
16.80
18.00
19.70
A94206XX
A94208XX
A94210XX
A94212XX
A94213XX
A94214XX
A94216XX
A94217XX
A94219XX
A94221XX
A94223XX
A94225XX
A94227XX
A942A11XX
A94228XX
A94256XX
A94230XX
A94257XX
A94232XX
A94258XX
A94234XX
A94235XX
A94237XX
A94259XX
A94238XX
A94241XX
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 150 C and ambient air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
18
23
28
32
35
42
49
56
66
74
85
103
120
137
162
182
213
231
260
278
320
353
394
435
467
538
A942
Catalogue
No
19
19
19
19
19
19
37
44
56
70
84
116
144
174
228
276
355
408
501
558
717
838
1019
1197
1347
1726
9
12
16
19
22
27
35
38
50
58
68
90
115
140
175
210
275
310
370
415
530
615
740
870
970
1216
0.19
0.24
0.27
0.30
0.33
0.38
0.30
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
