Wires & Cables
Product Construction
Technical Data
0
0
ü
Rated Temperature : - 40 C to +125 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5
Sq.mm)ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-5, ISO 6722
, Generally
as per
QC / T 1037-2016 **
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Stranded)
ü
Insulation : Electron Beam Cross Linked
Polyolefin
Class C (Thick Wall)
ü
Insulation
Colour
: Orange (or) As Per
Customer Request
Siechem
Single Core, Stranded Class C (Thick) 1000V AC EV 125 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(mm)
(Max.)
Conductor Construction
Over all Diameter
(mm)
Weight
Approx.
Insulation
Thickness
2
mm
nos.
kg/km
mm
Part
Number
*
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
37.1
24.7
18.5
14.9
12.7
9.42
7.60
6.15
4.71
3.94
3.14
2.38
1.82
1.52
1.16
0.955
0.743
0.647
0.527
0.473
0.368
0.315
0.259
0.219
0.196
0.153
Min.
Max.
1C x 0.5
1C x 0.75
1C x 1
1C x 1.25
1C x 1.5
1C x 2
1C x 2.5
1C x 3
1C x 4
1C x 5
1C x 6
1C x 8
1C x 10
1C x 12
1C x 16
1C x 20
1C x 25
1C x 30
1C x 35
1C x 40
1C x 50
1C x 60
1C x 70
1C x 85
1C x 95
1C x 120
19
19
19
19
19
19
37
44
56
70
84
116
144
174
228
276
355
408
501
558
717
838
1019
1197
1347
1726
0.48
0.48
0.48
0.48
0.48
0..48
0.56
0.56
0.64
0.64
0.64
0.64
0.80
0.80
0.80
0.88
1.04
1.04
1.04
1.12
1.20
1.20
1.20
1.28
1.28
1.28
2.00
2.20
2.40
2.40
2.70
3.00
3.30
3.80
4.00
4.50
4.60
5.00
5.90
6.60
7.70
8.10
9.40
9.70
9.60
11.20
11.50
13.40
13.50
14.80
16.00
17.70
2.30
2.50
2.70
2.95
3.00
3.30
3.60
4.10
4.40
4.90
5.00
5.90
6.50
7.40
8.30
9.10
10.40
10.90
11.60
12.40
13.50
14.60
15.50
16.80
18.00
19.70
9
12
16
19
22
27
35
38
50
58
68
90
115
140
175
210
275
310
370
415
530
615
740
870
970
1216
A93806XX
A93808XX
A93810XX
A93812XX
A93813XX
A93814XX
A93816XX
A93817XX
A93819XX
A93821XX
A93823XX
A93825XX
A93827XX
A938A11XX
A93828XX
A93856XX
A93830XX
A93857XX
A93832XX
A93858XX
A93834XX
A93835XX
A93837XX
A93859XX
A93838XX
A93841XX
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 125 C and ambient air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
17
21
25
29
32
38
44
51
60
68
77
94
109
124
147
166
193
210
236
253
291
321
359
396
424
489
A938
Catalogue
No
0.19
0.24
0.27
0.30
0.33
0.38
0.30
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
