Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
4G : EVA
ü
C : ATC Screening
ü
B : Al. Mylar Tape
ü
13X : EBXL-XLPO
ü
C : Asymmetrical (Structure C)
ü
Standard : ISO 6722, Class E & LV 216-2
ü
Conductor : Annealed Tinned Flexible Copper
Conductor (Asymmetrical, Structure C)
ü
Insulation : EVA (Thin wall)
ü
Inner Sheath : EBXL-XLPO
ü
Screen : ATC with Al-Mylar Tape
ü
Outer Sheath : EBXL-XLPO - Orange
ü
Colour : As Per Customer Order.
ü
Multi Core
Siechem
FHLR4GCB13X - C RoHS
FHLR4GCB13X - C
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A743E
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Inner
Sheath
(Min.)
Screen
Wire
Diameter
(Max.)
Dia
Over
Shielding
(Max.)
2
mm nos.
kg/km
mm
Part
Number
mm mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
mm
mm
mm
2 X 1.5
3 X 1.5
4 X 1.5
5 X 1.5
2 X 2.5
3 X 2.5
4 X 2.5
5 X 2.5
2 X 4.0
3 X 4.0
4 X 4.0
5 X 4.0
2 X 6.0
3 X 6.0
4 X 6.0
5 X 6.0
76
76
76
76
140
140
140
140
224
224
224
224
320
320
320
320
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
1.70
1.70
1.70
1.70
2.20
2.20
2.20
2.20
2.80
2.80
2.80
2.80
3.40
3.40
3.40
3.40
0.22
0.22
0.22
0.22
0.24
0.24
0.24
0.24
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
2.40
2.40
2.40
2.40
3.00
3.00
3.00
3.00
3.70
3.70
3.70
3.70
4.30
4.30
4.30
4.30
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
6.5
6.9
7.5
8.1
7.6
8.1
8.8
9.6
9.0
9.6
10.7
11.9
10.4
11.4
12.3
13.5
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.16
0.21
0.21
0.21
8.5
9.1
9.7
10.3
9.9
10.4
11.1
12.1
11.3
12.1
13.3
14.5
12.8
14.1
15.1
16.3
13.0
13.0
13.0
13.0
7.82
7.82
7.82
7.82
4.85
4.85
4.85
4.85
3.23
3.23
3.23
3.23
mm
ü
* Other length as per Customer order.
A743E1302
A743E1303
A743E1304
A743E1305
A743E1602
A743E1603
A743E1604
A743E1605
A743E1902
A743E1903
A743E1904
A743E1905
A743E2302
A743E2303
A743E2304
A743E2305
115
135
155
180
150
180
215
250
205
245
315
380
270
350
420
500
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
