Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
4G : EVA
ü
13X : EBXL-XLPO
ü
C : Asymmetrical (Structure C)
ü
Standard : ISO 6722, Class E & LV 216-2
ü
Conductor : Annealed Tinned Flexible Copper
Conductor (Asymmetrical, Structure C)
ü
Insulation : EVA (Thin wall)
ü
Inner Sheath : EBXL-XLPO
ü
Outer Sheath : EBXL-XLPO - Orange
ü
Colour : As Per Customer Order.
ü
Multi Core
Siechem
FHLR4G13X - C RoHS
FHLR4G13X - C
2D View
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
30
