EV Cables

32 / 82

A742
ü * Other length as per Customer order.
Catalogue
No
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+ Cr
Free
PBB
Free
PBDE
Free
31
All information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
Wires & Cables
Siechem FHLR4G13X - C RoHS
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Outer
Sheath
(Min.)
2 mm nos. kg/km mm
Part
Number
mm mm
Max.
Conductor
Resistance
0 at 20 C
Ω/km mm mm mm
2C X 4
3C X 4
4C X 4
5C X 4
2C X 6
3C X 6
4C X 6
5C X 6
224
224
224
224
320
320
320
320
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
2.80
2.80
2.80
2.80
3.40
3.40
3.40
3.40
3.70
3.70
3.70
3.70
4.30
4.30
4.30
4.30
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.76
0.76
0.80
0.90
0.90
1.00
1.00
1.00
9.7
10.3
11.3
12.5
11.0
11.8
13.0
14.3
4.85
4.85
4.85
4.85
3.23
3.23
3.23
3.23
A7421902
A7421903
A7421904
A7421905
A7422302
A7422303
A7422304
A7422305
150
185
235
290
210
270
340
405
