EV Cables

30 / 82

A741
Catalogue
No
ü * Other length as per Customer order.
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+ Cr
Free
PBB
Free
PBDE
Free
29
All information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Outer
Sheath
(Min.)
2 mm nos. kg/km mm
Part
Number
mm mm
Max.
Conductor
Resistance
0 at 20 C
Ω/km mm mm mm
2C X 4
3C X 4
4C X 4
5C X 4
2C X 6
3C X 6
4C X 6
5C X 6
56
56
56
56
84
84
84
84
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
2.80
2.80
2.80
2.80
3.40
3.40
3.40
3.40
3.70
3.70
3.70
3.70
4.30
4.30
4.30
4.30
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.76
0.76
0.80
0.90
0.90
1.00
1.00
1.00
9.7
10.3
11.3
12.5
11.0
11.8
13.0
14.3
150
185
235
290
210
270
340
405
4.85
4.85
4.85
4.85
3.23
3.23
3.23
3.23
A7411902
A7411903
A7411904
A7411905
A7412302
A7412303
A7412304
A7412305
Wires & Cables
Siechem FHLR4G13X - B RoHS
