Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ü
FHL : Automotive Cable (High Voltage)
ü
2G : Silicone Rubber
ü
C : Asymmetrical (Structure C)
ü
Standard : ISO 6722, Class E
ü
Conductor : Annealed Plain Flexible Copper
Conductor (Asymmetrical, Structure C)
ü
Insulation : Silicone Rubber (Thick wall)
ü
Colour : As Per Customer Order
ü
Single Core
Siechem
FHL2G - C RoHS
FHL2G - C
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
ü
* Other length as per Customer order.
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
2
mm
nos.
kg/km
mm
Part
Number
mm
mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
1.10
1.30
1.50
1.70
2.20
2.80
3.40
4.50
5.80
7.20
8.50
10.50
12.50
14.80
16.50
0.48
0.48
0.48
0.48
0.56
0.64
0.64
0.80
0.80
1.04
1.04
1.20
1.20
1.28
1.28
2.30
2.50
2.70
3.00
3.60
4.40
5.00
6.50
8.30
10.40
11.60
13.50
15.50
18.00
19.70
37.1
24.7
18.5
12.7
7.60
4.71
3.14
1.82
1.16
0.743
0.527
0.368
0.259
0.196
0.153
0.5
0.75
1.0
1.5
2.5
4
6
10
16
25
35
50
70
95
120
26
38
54
76
140
224
320
320
512
790
1070
1600
1427
1936
2450
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.21
0.21
0.26
0.26
0.26
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A745S
35
www.siechem.comAll information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
A745S06XX
A745S08XX
A745S10XX
A745S13XX
A745S16XX
A745S19XX
A745S23XX
A745S27XX
A745S28XX
A745S30XX
A745S32XX
A745S34XX
A745S37XX
A745S38XX
A745S41XX
9
12
15
20
30
45
65
110
170
265
330
510
705
920
1160
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
