www.siechem.comProduct Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
4G : EVA
ü
13X : EBXL-XLPO
ü
C : Asymmetrical (Structure C)
ü
Standard : ISO 6722 & Class E & LV 216-2
ü
Conductor : Annealed Plain Flexible Copper
Conductor (Asymmetrical, Structure C)
ü
Insulation : EVA (Thin wall)
ü
Outer Sheath : EBXL-XLPO- Orange
ü
Colour : As Per Customer Order.
ü
Single Core
Siechem
FHLR4G13X - C RoHS
FHLR4G13X - C
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Outer
Sheath
(Min.)
2
mm nos.
kg/km
mm
Part
Number
mm
mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
mm
mm
0.5
0.75
1
1.5
2.5
4
6
26
38
54
76
140
224
320
1.10
1.30
1.50
1.70
2.20
2.80
3.40
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.22
0.24
0.24
0.24
0.28
0.32
0.32
1.60
1.90
2.10
2.40
3.00
3.70
4.30
0.38
0.38
0.38
0.38
0.38
0.38
0.46
3.0
3.4
3.6
3.9
4.5
5.2
6.0
13
16
19
25
37
55
78
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A739S
37.1
24.7
18.5
12.7
7.60
4.71
3.14
ü
* Other length as per Customer order.
A739S06XX10
A739S08XX10
A739S10XX10
A739S13XX10
A739S16XX10
A739S19XX10
A739S23XX10
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
All information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
