Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
2G : Silicone Rubber
ü
C : ATC Screening
ü
B : Al. Mylar Tape
ü
2G : Silicone Rubber
ü
C : Asymmetrical (Structure C)
ü
Standard : ISO 6722, Class E & LV 216-2
ü
Conductor : Annealed Tinned Flexible Copper
Conductor (Asymmetrical, Structure-C)
ü
Taping : Optional
ü
Insulation : Silicone Rubber (Thin wall)
ü
Inner Sheath : Silicone Rubber
ü
Screen : ATC with Al-Mylar Tape
ü
Outer Sheath : Silicone Rubber - Orange
ü
Colour : As Per Customer Order.
ü
Multi Core
Siechem
FHLR2GCB2G - C RoHS
FHLR2GCB2G - C
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Inner
Sheath
(Min.)
Screen
Wire
Diameter
(Max.)
Dia
Over
Shielding
(Max.)
2
mm nos.
kg/km
mm
Part
Number
mm mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
mm
mm
mm
2 X 1.5
3 X 1.5
4 X 1.5
5 X 1.5
2 X 2.5
3 X 2.5
4 X 2.5
5 X 2.5
2 X 4.0
3 X 4.0
4 X 4.0
5 X 4.0
2 X 6.0
3 X 6.0
4 X 6.0
5 X 6.0
76
76
76
76
140
140
140
140
224
224
224
224
320
320
320
320
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
1.70
1.70
1.70
1.70
2.20
2.20
2.20
2.20
2.80
2.80
2.80
2.80
3.40
3.40
3.40
3.40
0.22
0.22
0.22
0.22
0.24
0.24
0.24
0.24
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
2.40
2.40
2.40
2.40
3.00
3.00
3.00
3.00
3.70
3.70
3.70
3.70
4.30
4.30
4.30
4.30
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
0.38
6.5
6.9
7.5
8.1
7.6
8.1
8.8
9.6
9.0
9.6
10.7
11.9
10.4
11.4
12.3
13.5
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.16
0.21
0.21
0.21
8.5
9.1
9.7
10.3
9.9
10.4
11.1
12.1
11.3
12.1
13.3
14.5
12.8
14.1
15.1
16.3
13.0
13.0
13.0
13.0
7.82
7.82
7.82
7.82
4.85
4.85
4.85
4.85
3.23
3.23
3.23
3.23
mm
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A737E
ü
* Other length as per Customer order.
A737E1302
A737E1303
A737E1304
A737E1305
A737E1602
A737E1603
A737E1604
A737E1605
A737E1902
A737E1903
A737E1904
A737E1905
A737E2302
A737E2303
A737E2304
A737E2305
110
130
150
175
145
175
205
245
195
235
305
365
260
335
410
485
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
