EV Cables

81 / 82

Basic code lettersConductor materialDesign featureInsulation materialNon-extrued coatingNon-extrued coatingSheathing material
Automotive cable nominal voltage Max. 60 V
Order form inside to outside
Conductor material copper
1.Screen : Braided Screen
2.Screen : Screening foil
Sheathing material made of TPE-U
Insulation, reduced wall thickness
thin wall according to ISO 6722
Core Insulation made of TPE-S
FHL R 4G C B 13X
Basic code lettersConductor materialDesign featureInsulation materialNon-extrudedCoatingNon-extrudedCoatingSheathing material
Automotive high-voltage cable
Order form inside to outside
Conductor material copper
2. Screen : Screening foil
1. Screen : Braided Screen
Sheathing material made of silicone rubber
Insulation, reduced wall thickness
thin wall according to ISO 6722
Core Insulation made of Silicone rubber
FHL2GCB2G
FHLR4GCB13X
FHL 2G C B 2G
Screening measures non- extruded coating
Insulation wall thickness
Designation
Designation
Meaning
Meaning
B
V
R
U
S
Foil screen electric screening
Braid, metallic electric screening
Reduced Wall thickness thin wall according to ISO 6722
Ultra- reduced wall thickness ultra thin wall accoriding to ISO 6722
Special wall thickness
80
