Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper Conductor
ü
Insulation : EBXL- XLPO
ü
Individual Shield : Al.Mylar Tape
ü
Individual Screen : ATC
ü
Collective Shield : Al.Mylar Tape
ü
Inner Sheath : EBXL -XLPO
ü
Outer Sheath : TPU - Black
ü
Colour :
i) 2Cx50
Sq.mm- Brown, Blue
ii) 1Cx25
Sq.mm- Yellow/Green
iii) 2Cx0.75
Sq.mm- Green, White
iv) 4Cx0.5
Sq.mm- Brown -Yellow
Red, Purple
or As Per Customer Order
ü
Composite Cable
ü
Electrical Properties :
ü
Rated temperature : -40°C + 125°C
Jacket : -40°C + 90°C
ü
Min.Insulation volume resistance at 20°C : 36.7 MΩ/km
ü
Dielectric : Power Core : 2.5 kV AC / 5 min
Control Core : 1.5 kV AC / 5 min
ü
Min. Binding Radius : 6 X Cable OD
ü
Flame Resistance : Single Cable Flame Test
ü
Insulation tensile Strength :
ü
Before aging : 8Mpa : After Aging : (135°C/168H)≥ 70%
ü
Insulation elongation :
ü
Before aging : 200Mpa : After Aging : (135°C/168H)≥ 70%
ü
Jacket tensile Strength :
ü
Before aging : 20\Mpa : After Aging : (110°C/168H)≥ 70%
ü
Jacket elongation :
ü
Before aging : 300Mpa : After Aging : (110°C/168H)≥ 70%
ü
: 300Mpa : After Aging : (110°C/168H)≥ 70%
ü
Oil resistance : Gasoline, IRM903#, IRM902#,
OD Variation ± 15%, No Cracking.
ü
Resistance against acid and
alkaline at 23°C : 168H Tensile Strength Variation ± 30 %
Elongation ≥ 100 %
ü
Cold bend : - 40°C 16 hours, No Crack
ü
Hot shock : 150°C 1 hours, No Crack
ü
Extrusion test : ≥ 15 KN
ü
RoHS and REACH : Complies
ü
life time Min : Expected Period use 25 Year
ü
life time Min : Expected for Periord of 20000 hrs at Max.
Conductor operating temperature
ü
RoHS and REACH : Complies
ü
low Smoke, Halogen free &free &frame Retardant : Complies
ü
Packing Lentght : Multiples of 300
Siechem (2C X 50 + 1C X 25) + (2C X 0.75 + 4C X 0.5) TPU Outer Sheathed EV Charging Cable
2C X 50 +
1C X 25 +
2C X 0.75
A7263709
1657/0.196
829/0196
0.386
0.78
1.4
1.2
12.8 ± 0.30
9.60 ± 0.25
-
-
Al.Mylar
Tape
-
-
-
Al.Mylar
Tape
-
-
-
-
-
-
-
-
-
Wires & Cables
77
www.siechem.comAll information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
No. of Stands
/ Stand dia
Max.
DC. Conductor
Resistance
at 20° C
Thickness of
Insulation
(Nom)
Dia. Over
Insulation
(Nom)
Individual
Shielding
Material
Individual
Braiding
Wire Dia
(Nom.)
Collective
Shielding
Material
Collective
Braiding
Wire Dia.
(Nom.)
Thickness of
Outer Sheath
No.ofcore x
Nominal Cross
Sectional Area
Part
number
Ω / km mm mm
mm
mm
(Nom)
17/0.196
Inner
Sheath
Thickness
(Nom.)
0.6
0.2
32.5 ± 1.0 1940
Overall
Diameter
of Cable
(Nom)
Approx
Cable
Weight
2.7
mm
mm
mm kg/km
2.3. ± 0.15
0.50
4C X 0.5
39.0
0.12
0.5
Nos x sqmm
Nos x sqmm
2D View
25/0.196
26.0
0.50 2.5 ± 0.15
Catalogue
No.
A726
Siechem (2C X 70 + 1C X 25) + (5C X 0.75 + 1C X 0.75) TPU Outer Sheathed EV Charging Cable
i
5 ) (2 . 4 0.5) TPU Outer Sheathed EV Charging Cable
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
