Catalogue
No.
A726
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper Conductor
ü
Insulation : EBXL- XLPO
ü
Individual Shield : Al.Mylar Tape
ü
Individual Screen : ATC
ü
Collective Shield : Al.Mylar Tape
ü
Collective Screen : ATC
ü
Inner Sheath : EBXL -XLPO
ü
Tapping : Water Swellable tape
ü
Outer Sheath : TPU - Black
ü
Colour :
i) 2Cx70
Sq.mm- Red, Black
ii) 1Cx25
Sq.mm- Green/Yellow
iii) 5Cx0.75
Sq.mm- Orange, Purple, Blue,
Brown & Grey
iv) 1Cx0.75
Sq.mm- White
or As Per Customer Order
ü
Composite Cable
ü
Electrical Properties :
ü
Min.Insulation Volume Resistance at 20°C : 36.7 MΩ/km
ü
Dielectric : Power Core : 2.5 kV AC / 5 min
Control Core : 1.5 kV AC / 5 min
ü
Mechanical Properties :
ü
Tensile Strength (Before Ageing)
i) Insulation : >8 Mpa
ii) Sheath : >13 Mpa
ü
Elongation (Before Ageing)
i) Insulation : >200%
ii) Sheath : >250%
ü
Oil Resistance : Gasoline, IRM903#, IRM902#,
OD Variation ± 15%, No Cracking.
ü
Resistance against acid and
alkaline at 23°C : 168H Tensile Strength Variation ± 30 %
Elongation ≥ 100 %
ü
Cold Bend : - 40°C 16 hours, No Crack
ü
Hot Shock : 150°C 1 hours, No Crack
ü
Fire Properties :
ü
Flame Resistance : Single Cable as per IEC 60332-1-2
ü
Low Smoke, Halogen Free & Flame Retardant : Complies
ü
RoHS and REACH : Complies
ü
Bending Radius, Min : 10 X Cable OD
Siechem (2C X 70 + 1C X 25) + (5C X 0.75 + 1C X 0.75) TPU Outer Sheathed EV Charging Cable
2C X 70 +
1C X 25 +
5C X 0.75 +
A7263709
2235/0.20
800/0.20
42/0.15
0.272
0.786
26.0
1.6
1.2
0.6
15.0 ± 0.50
9.60 ± 0.30
2.40 ± 0.20
-
-
-
Al.Mylar
Tape
-
-
-
-
-
-
-
-
-
Wires & Cables
No. of Stands
/ Stand dia
Max.
DC. Conductor
Resistance
at 20° C
Thickness of
Insulation
(Nom)
Dia. Over
Insulation
(Nom)
Individual
Shielding
Material
Individual
Braiding
Wire Dia
(Nom.)
Collective
Shielding
Material
Collective
Braiding
Wire Dia.
(Nom.)
Thickness of
Outer Sheath
No.ofcore x
Nominal Cross
Sectional Area
Part
number
Ω / km mm mm
mm
mm
Nom
42/0.15
Al.Mylar
Tape
Inner
Sheath
Thickness
(Nom.)
0.5
36.0 ± 1.0 2830
Overall
Diameter
of Cable
(Nom)
Approx
Cable
Weight
Max
2.5 3.0
mm
mm
mm kg/km
2.40 ± 0.20
0.6
1C X 0.75
26.0
0.12
0.10
Nos x sqmm
Nos x sqmm
2D View
Siechem (2C X 70 + 1C X 25) + (5C X 0.75 + 1C X 0.75) TPU Outer Sheathed EV Charging Cable
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
