Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Flexible)
ü
Insulation : Electron Beam Cross Linked
Polyolefin Class D (Thin wall)
ü
Insulation Colour : As per ISO 19642-1
ü
Screening : Annealed Tinned Copper
Conductor
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) As Per
Customer Order
Siechem
Single Core Screened, Flexible Class D (Thin) 1000V AC EV 150 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Over all Diameter
Weight
Approx.
Insulation
Thickness
2
mm nos.
kg/km
mm
Part
Number
*
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
mm
12.7
9.42
7.6
6.15
4.71
3.94
3.14
2.38
1.82
1.52
1.16
0.955
0.743
0.647
0.527
0.473
0.368
0.315
0.259
0.219
0.196
Min.
Max.
1C x 1.5
1C x 2
1C x 2.5
1C x 3
1C x 4
1C x 5
1C x 6
1C x 8
1C x 10
1C x 12
1C x 16
1C x 20
1C x 25
1C x 30
1C x 35
1C x 40
1C x 50
1C x 60
1C x 70
1C x 85
1C x 95
182
245
140
160
224
250
189
240
320
380
512
610
790
903
1102
1235
1600
1841
2147
2660
3000
0.11
0.11
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.24
0.28
0.28
0.32
0.32
0.32
0.32
0.32
0.48
0.48
0.52
0.52
0.52
0.64
0.64
0.71
0.71
0.80
0.80
0.90
0.90
0
0
ü
Rated Temperature : - 40 C to +150 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5 Sqmm)
ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722, Generally
as per QC / T 1037-2016**
mm
0.13
0.13
0.13
0.16
0.16
0.16
0.16
0.19
0.19
0.19
0.19
0.19
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.26
0.26
Sheath
Thickness
(Nom.)
A95913XXYY
A95914XXYY
A95916XXYY
A95917XXYY
A95919XXYY
A95921XXYY
A95923XXYY
A95925XXYY
A95927XXYY
A959A11XXYY
A95928XXYY
A95956XXYY
A95930XXYY
A95957XXYY
A95932XXYY
A95958XXYY
A95934XXYY
A95935XXYY
A95937XXYY
A95959XXYY
A95938XXYY
3.3
3.7
3.9
4.2
4.5
5.4
5.5
6.5
7.5
8.0
9.0
9.6
10.7
11.6
12.6
13.3
14.6
15.5
16.6
18.2
19.1
0.40
0.40
0.40
0.40
0.40
0.60
0.60
0.65
0.65
0.65
0.80
0.80
0.90
0.90
1.00
1.00
1.10
1.10
1.10
1.10
1.10
mm
Screen
Wire dia
(Max.)
3.7
4.1
4.3
4.8
5.1
6.0
6.1
7.1
8.1
8.6
9.6
10.2
11.3
12.2
13.2
13.9
15.2
16.3
17.4
19.0
19.9
Note : XX*YY* : Please add last two digits in the part number as per the colour code given hereunder replacing XX,YY while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 150 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
35
42
49
56
66
74
85
103
120
135
162
188
213
235
263
290
327
370
418
475
516
A959
Catalogue
No
36
43
49
58
73
86
102
132
170
193
253
290
365
410
490
540
675
770
880
1080
1200
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
