Wires & Cables
Product Construction
Technical Data
ü
Conductor : Annealed Plain Copper
Conductor according to ISO 19642 (Flexible)
ü
Insulation : Electron Beam Cross Linked
Polyolefin Class C (Thick Wall)
ü
Insulation color : As per ISO 19642-1
ü
Braiding : Annealed Tinned Copper Conductor
ü
Screening : Al. Mylar Tape
ü
Sheath : Electron Beam Crossed Linked
Polyolefin
ü
Sheath Colour : Orange (or) As Per
Customer Order
Siechem
Multi Core Screened with Foil, Flexible Class C (Thick) 1000V AC EV 125 Cable
2D View
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(Max)
Conductor Construction
Overall
Diameter
Max.
Weight
Approx.
Insulation
Thickness
2
mm nos.
kg/km
mm
Part
Number
Max.
Conductor
Resistance
0
at 20 C
Ω/km
(Min.)
mm
mm
Current
Carrying
Capacity
Amps
12.7
12.7
12.7
7.60
7.60
7.60
4.71
4.71
4.71
3.14
3.14
3.14
1.82
1.82
1.16
1.16
.
182
182
182
140
140
140
224
224
224
189
189
189
320
320
512
512
0.11
0.11
0.11
0.16
0.16
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.48
0.48
0.48
0.56
0.56
0.56
0.64
0.64
0.64
0.64
0.64
0.64
0.80
0.80
0.80
0.80
0
0
ü
Rated Temperature : - 40 C to +125 C (3000 Hours)
ü
Max. Rated Voltage : 1000V AC / 1500V DC
ü
Test Voltage : 10kV AC for 5 mins (≥ 0.5 Sqmm)
ü
Insulation Faults : 8kV AC
ü
Specification : ISO 19642-9, ISO 6722, Ganerally
as per QC / T 1037-2016**
mm
0.19
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.26
0.26
0.26
0.26
0.26
Sheath
Thickness
(Min.)
A9651302
A9651303
A9651304
A9651602
A9651603
A9651604
A9651902
A9651903
A9651904
A9652302
A9652303
A9652304
A9652702
A9652703
A9652802
A9652803
10.3
10.9
11.9
11.9
12.5
13.6
13.8
14.6
15.9
15.2
16.1
17.7
18.8
19.9
22.8
24.2
1.01
1.04
1.07
1.07
1.10
1.13
1.14
1.16
1.20
1.18
1.21
1.25
1.27
1.30
1.35
1.38
mm
Screen
Wire dia
(Max.)
165
198
235
237
280
335
325
385
470
405
495
615
630
775
865
1075
2C x 1.5
3C x 1.5
4C x 1.5
2C x 2.5
3C x 2.5
4C x 2.5
2C x 4
3C x 4
4C x 4
2C x 6
3C x 6
4C x 6
2C x 10
3C x 10
2C x 16
3C x 16
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
0.065
mm
Foil
Thickness
(Max.)
28
25
23
39
34
32
53
46
43
68
59
55
96
84
130
113
Note :
o
o
ü
Current Carrying capacity given is for the maximum conductor operating of 125 C and
ambient
air temperature of 40 C.
ü
** Conductor construction as per ISO 19642-5. If customer insist construction to be as per ISO 6722 & Generally as per QC/ T1037-2016 or any specific construction, the same can also be supplied.
A965
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
