Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
2G : Silicone Rubber
ü
2G : Silicone Rubber
ü
B : Asymmetrical (Structure B)
ü
Standard : ISO 6722, Class E & LV 216-2
ü
Conductor : Annealed Tinned Flexible Copper
Conductor (Asymmetrical, Structure B)
ü
Taping : Optional
ü
Insulation : Silicone Rubber (Thin wall)
ü
Inner Sheath : Silicone Rubber
ü
Outer Sheath : Silicone Rubber - Orange
ü
Colour : As Per Customer Order.
ü
Multi Core
Siechem
FHLR2G2G - B RoHS
FHLR2G2G - B
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Insulation
Thickness
(Min.)
Core
Diameter
(Max.)
Thickness
of Outer
Sheath
(Min.)
2
mm nos.
kg/km
mm
Part
Number
mm
mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
mm
mm
2C X 0.5
3C X 0.5
4C X 0.5
5C X 0.5
2C X 0.75
3C X 0.75
4C X 0.75
5C X 0.75
2C X 1
3C X 1
4C X 1
5C X 1
2C X 1.5
3C X 1.5
4C X 1.5
5C X 1.5
2C X 2.5
3C X 2.5
4C X 2.5
5C X 2.5
16
16
16
16
24
24
24
24
32
32
32
32
30
30
30
30
50
50
50
50
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.21
0.26
0.26
0.26
0.26
0.26
0.26
0.26
0.26
1.10
1.10
1.10
1.10
1.30
1.30
1.30
1.30
1.50
1.50
1.50
1.50
1.70
1.70
1.70
1.70
2.20
2.20
2.20
2.20
1.60
1.60
1.60
1.60
1.90
1.90
1.90
1.90
2.10
2.10
2.10
2.10
2.40
2.40
2.40
2.40
3.00
3.00
3.00
3.00
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.24
0.24
0.24
0.24
0.35
0.40
0.40
0.40
0.50
0.55
0.55
0.55
0.60
0.65
0.65
0.65
0.76
0.76
0.76
0.76
0.76
0.76
0.76
0.76
4.6
5.0
5.4
6.0
5.4
5.9
6.4
7.0
6.0
6.4
7.0
7.7
6.6
7.1
7.8
8.5
8.0
8.5
9.5
10.5
25
30
40
50
35
45
55
65
45
60
70
85
65
80
100
120
95
120
150
180
38.2
38.2
38.2
38.2
25.4
25.4
25.4
25.4
19.1
19.1
19.1
19.1
13.0
13.0
13.0
13.0
7.82
7.82
7.82
7.82
A7350602
A7350603
A7350604
A7350605
A7350802
A7350803
A7350804
A7350805
A7351002
A7351003
A7351004
A7351005
A7351302
A7351303
A7351304
A7351305
A7351602
A7351603
A7351604
A7351605
A735
ü
* Other length as per Customer order.
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
