Wires & Cables
Note :
ü
X - No. of Control Cable
ü
E - Earthing
Product Construction
Technical Data
ü
Rated Temperature :
0
0
Static : - 40 C to +90 C
0
0
Dynamic : - 35 C to +90 C
ü
Rated Voltage : 300/500V
ü
Test Voltage : 2.5 KV AC
(1 Hour in water both)
ü
Bending Radius :
Static : 5 X Cable OD
Dynamic : 15 X Cable OD
ü
Specification : EN 50620 : 2017
Nominal
Cross-
Section
No. of
Strands
Stand dia.
(mm)
(Max.)
Conductor Construction
Sheath
Thickness
Nom.
Insulation
Thickness
2
mm
nos.
mm
Part
Number
*
Max.
Conductor
Resistance
0
at 20 C
Ω/km
Nom.
mm
mm
13.3
7.98
Siechem
3C X 1.5 + 1C X 0.5
Sq.mmH05BZ5-F 300/500V EV Cable
2D View
(3C X 1.5)+0.5
(3C X 2.5)+0.5
0.26
0.26
0.6
0.6
7.9
9.1
10.1
11.5
Overall Diameter
1.0
1.0
Min.
Max.
30
50
ü
Conductor : Annealed Plain Copper Conductor
(Optional: Tinned) according to 60228
ü
Insulation : EVI-2
ü
Control cable : CP/CC (Control pilot/control core)
as per customer request
ü
Conductor : Annealed Plain Copper Conductor
ü
Insulation : EVI-2
ü
Sheath : EVM-1
ü
Sheath Colour : Orange (or) as per customer request
A9711303XE
A9711603XE
mm
mm
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A971
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal
for high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
