17 / 82
Siechem Wires & Cables Meet EU RoHS Directive
Lead
Free
Hg
Free
Cd
Free
6+
Cr
Free
PBB
Free
PBDE
Free
A721S
16
www.siechem.comAll information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and
Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction.
Product Construction
Technical Data
Wires & Cables
ü
Voltage Rating : 600V AC / 1000V DC
ü
Temperature Range :
- 40˚C to +180˚C (3000 Hours)
ü
Test Voltage :
2
i) Insulation : 6 kV for cables < 0.5 mm
2
8 kV for cables ≥ 0.5 mm
ii) Outer Jacket : 8 kV for all cables
ü
FHL : Automotive Cable (High Voltage)
ü
R : Reduced wall thickness
ü
2G : Silicone Rubber
ü
C : ATC Screening
ü
B : AI. Mylar Tape
ü
2G : Silicone Rubber
ü
B : Asymmetrical (Structure B)
ü
Standard : ISO 6722, Class E & LV 216-2
ü
Conductor :
Annealed Plain Flexible Copper
Conductor
(Asymmetrical, Structure B)
ü
Taping : Optional
ü
Insulation : Silicone Rubber (Thin wall)
ü
Screen : ATC Screen with Al. Mylar Tape
ü
Outer Sheath : Silicone Rubber - Orange
ü
Colour : As Per Customer Order.
ü
Single Core
Siechem
FHLR2GCB2G - B RoHS
FHLR2GCB2G - B
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08
White - 09
Orange - 10
Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14
LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19
Purple - 20
Pink - 21
Nominal
Cross-
Section
No. of
Strands
Diameter of
Single wire
(Max.)
Conductor Construction
Conductor
Diameter
(Max.)
Cable
Overall
Diameter
Weight
Approx.
(Max.)
Core
Diameter
(Max.)
Screen
Wire
Diameter
(Max.)
Outer
Sheath
Thickness
(Min.)
2
mm nos.
kg/km
mm
Part
Number
mm
mm
Max.
Conductor
Resistance
0
at 20 C
Ω/km
mm
mm
mm
mm
1.5
2.5
4.0
6.0
10
16
25
35
50
70
95
120
30
50
56
84
80
126
196
276
396
360
475
608
0.26
0.26
0.31
0.31
0.41
0.41
0.41
0.41
0.41
0.51
0.51
0.51
1.7
2.2
2.8
3.4
4.5
5.8
7.2
8.5
10.5
12.5
14.8
16.5
0.24
0.28
0.32
0.32
0.48
0.52
0.64
0.64
0.71
1.20
1.20
1.28
2.40
3.00
3.70
4.30
6.00
7.20
8.80
10.50
12.20
15.50
18.00
19.70
0.11
0.11
0.16
0.16
0.16
0.16
0.21
0.21
0.21
0.21
0.21
0.21
0.38
0.38
0.38
0.46
0.70
0.70
0.75
0.80
0.80
1.16
1.16
1.16
4.00
4.70
5.80
6.50
8.80
10.20
12.20
14.40
15.80
20.00
22.50
23.50
35
50
75
100
160
230
350
475
650
920
1175
1440
12.7
7.60
4.71
3.14
1.82
1.16
0.743
0.527
0.368
0.259
0.196
0.153
Insulation
Thickness
(Min.)
A721S13XX10
A721S16XX10
A721S19XX10
A721S23XX10
A721S27XX10
A721S28XX10
A721S30XX10
A721S32XX10
A721S34XX10
A721S37XX10
A721S38XX10
A721S41XX10
ü
* Other length as per Customer order.
2D View
Catalogue
No
OHSAS
18001
AS
9100
ISO
45001
ISO
9001
ISO
14001
IATF
16949
Application
Features
ü
Electrical vehicle charging station
ü
Portable cables for hybrid & electric vehicles
ü
Designed to be installed (both indoors
and outdoors) at private homes, communal
blocks, companies & other places
ü
Enchanced DV power rating makes it ideal for
high powered charging stations
ü
Designed to be installed in public access
environment likes urban spaces, shopping
centre, car park, airport etc.
ü
Suitability for installation with possibility of
water immersion
ü
Designed for harsh mechanical environments.
ü
Chemical and abrasion resistant.
ü
Hydrolyse resistant.
ü
Thermal stress resistant.
ü
Halogen free.
ü
Flame resistant.
ü
High flexibility and easy to use.
ü
Light weight, thin diameter.
ü
Cable is constructed to prevent injury and leakage.
ü
Low corrosive gas emission.
