Rubber cable
Wires & Cables Part Number Outer Diameter (mm) approx. Weight (Kg/Km) approx. 12 www.siechem.com All information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction. Catalogue No 508 Thickness of Insulation (mm) Thickness of Outersheath (mm) 1C X 2.5 1C X 4 1C X 6 1C X 10 1C X 16 1C X 25 1C X 35 1C X 50 1C X 70 1C X 95 1C X 120 1C X 150 1C X 185 1C X 240 1C X 300 1C X 400 1C X 500 1C X 630 2.01 2.55 3.12 4.05 5.00 6.10 7.20 8.60 10.20 12.00 13.50 15.00 16.80 19.20 22.00 25.00 28.80 32.70 1.00 1.00 1.00 1.10 1.10 1.20 1.20 1.30 1.40 1.40 1.5 1.6 1.7 1.8 1.9 2 2.2 2.3 8.63 10.25 11.96 15.15 18.00 21.50 24.80 29.20 34.20 39.60 44.30 49.00 54.60 62.00 70.80 80.00 91.80 103.70 104.11 149.91 207.74 335.56 487.42 711.94 959.18 1339.75 1846.73 2480.34 3111.03 3830.70 4742.42 6121.76 7869.52 10182.59 13174.86 16731.31 50816XX 50819XX 50823XX 50827XX 50828XX 50830XX 50832XX 50834XX 50837XX 50838XX 50841XX 50842XX 50844XX 50846XX 50848XX 50849XX 50850XX 50851XX Copper Index (Kg/Km) 21.11 33.78 50.67 84.46 135.13 211.14 295.59 422.28 591.19 802.32 1013.46 1266.83 1562.42 2026.92 2533.65 3378.20 4222.75 5320.67 Product Construction Technical Data ü Conductor : Annealed Tinned Copper, Class 2. (Optional - Aluminium Conductor as per Customer requirement) ü Separator Tape (Optional) ü Insulation : General Service elastomeric, Type IE 1 as per IS 6380-1984 (Optional : Heat Resisting elastomer, Type IE 2 as per IS 6380-1984) ü Outer Sheath : General Purpose Sheath Type SE 1 as per IS 6380-1984 (Optional : Heat resisting elastomer Type SE 2 as per IS 6380-1984) ü Temperature Range : 0 Insulation for General Service : 60 C 0 Heat Resisting Insulation : 90 C ü Test Voltage : 3 kV for 5 mins ü Rated Voltage : 1.1 kV ü Specification : IS 9968 Part - 1 Siechem Annealed Tinned Copper Conductor Synthetic Elastomeric Insulated, Sheathed Single Core Rubber Cable as per IS 9968 Part-1 SiechemAnnealed Tinned Copper Conductor Synthetic Elastomeric Insulated, Sheathed Single Core Rubber Cable Application Features ü Used for measuring & controlling in control equipment for conveyors and control units ü Fixed installation and for flexible use when temporarily moved in medium mechanical condition ü Used outdoors when protected and in dry or moist conditions indoor. ü Suitable for many applications, including use in elevators, lifts, cranes, mines, heater leads, and electric iron leads etc. ü Flexible ü Abrasion Resistance ü High Dielectric Strength ü Flame Retardant ü Medium Mechanical Stress ü Long Cable life. st 1 time in India EBXL Rubber Cable as per IS 9968 with enhanced properties No.of Cores X Conductor size 2 (Nos X mm ) AS 9100 ISO 45001 ISO 9001 ISO 14001
