Automotive cable

A761 www.siechem.com All information given are in good faith.Siechem's liability is only to replace the defective portion of cables provided the same is mutually established as manufacturing defects within the guarantee period as agreed in writing and Siechem shall not be liable for any compensation or damages. Siechem reserves the right to revise any of the above specifications without prior intimation. Subject to Chennai Jurisdiction. Application Product Construction Technical Data Wires & Cables 2D View Siechem FLR2X T4 (B) Class D RoHS 0 0 ü Temperature Range: -40 C to +150 C (3000 Hours) ü Standard : ISO 6722 Class D (Thin wall) 2 ü Test Voltage: 3kV (r.m.s.) for cables < 0.5 mm 2 5kV (r.m.s.) for cables ≥ 0.5 mm ü FL : Automotive Cable ü R : Reduced wall Thickness ü 2X : Cross Linked PE ü T4 : Temperature : -40°C to +150°C ü B : Asymmetrical Conductor (Structure B) Features ü Conductor : Soft / annealed Plain Copper according to ASTM B3 ü Insulation : Electron Beam Cross Linked Polyethylene ü Colour : As per customer order ü Cable construction according to ISO 6722, Class D (Thin wall) ü Single core, Single layer insulation Wires & Cables ü Low-tension electric wire for Automobiles. ü Used in Motorcycles and other motor vehicles for starting, charging, lighting, signal and instrument panel circuits. ü Flame retardant ü Highly resistant against acids, lyes, Petrol and diesel. ü Halogen free Catalogue No Nominal Cross- Section No. of Strands Diameter of Single wire Max. Conductor Construction Conductor Diameter Max. Cable Overall Diameter Weight Approx. Min. Insulation Wall Thickness Nom. 2 mm nos. mm mtrs kg/km mm Standard Length* Part Number mm mm o o ü Current Carrying capacity given is for the maximum conductor operating of 150 C and ambinet air temperature of 40 C. ü * Other length as per Customer order. * Max. Conductor Resistance 0 at 20 C Ω/km 0.35 0.50 0.75 1 1.5 2 2.5 3 4 5 6 10 16 25 35 50 70 95 0.25 0.28 0.30 0.30 0.30 0.35 0.35 0.40 0.40 0.40 0.40 0.60 0.65 0.65 0.80 0.90 1.00 1.10 54.4 37.1 24.7 18.5 12.7 9.42 7.60 6.15 4.71 3.94 3.14 1.82 1.16 0.743 0.527 0.368 0.259 0.196 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 12 16 24 32 30 28 50 44 56 65 84 80 126 196 276 396 360 475 0.21 0.21 0.21 0.21 0.26 0.31 0.26 0.31 0.31 0.33 0.31 0.41 0.41 0.41 0.41 0.41 0.51 0.51 5 6 9 12 17 23 26 34 42 53 60 106 165 249 350 495 685 930 0.90 1.10 1.30 1.50 1.80 2.00 2.20 2.40 2.80 3.10 3.40 4.50 5.80 7.20 8.50 10.50 12.50 14.80 A76105XX A76106XX A76108XX A76110XX A76113XX A76114XX A76116XX A76117XX A76119XX A76121XX A76123XX A76127XX A76128XX A76130XX A76132XX A76134XX A76137XX A76138XX Current Carrying Capacity Amps 12 16 22 26 33 41 46 54 64 72 82 119 158 208 257 321 396 469 FLR2X T4 (B) 1.20 1.40 1.70 1.90 2.20 2.50 2.70 3.10 3.40 3.90 4.00 5.30 6.40 7.90 9.40 11.00 13.00 15.30 1.40 1.60 1.90 2.10 2.40 2.80 3.00 3.40 3.70 4.20 4.30 6.00 7.20 8.70 10.40 12.20 14.40 16.70 Max. mm Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering. Red-01 Yellow-02 Blue-03 Black-04 Green-05 Grey-07 Brown-08 White-09 Orange-10 Violet-11 LTGreen-17 Yellow-Blue-26 Yellow-Pink-27 Black-Orange-38 Green-Black-42 Grey-Blue-50 Orange-Blue-70 Violet-Grey-75 Violet-Blue-76 Beige-Blue-86 Orange-Violet-A21 Green-Pink-A28 Violet-Brown-A50 LTBlue-White-A52 LTBlue-Orange-A54 Black-LTBlue-A57 Red-LTBlueA61 LTGreen-White-A65 Yellow-Beige-A73 LTBlue-Brwon-A56 Violet-LTBlue-A51 Pink-21 Green-Red-43 Green-Grey-44 Green-Yellow-29 Green-Brown-45 Grey-White-46 Grey-Violet-48 Brown-Blue-52 Grey-green-51 Brown- Grey-53 Brown-Orange-55 Brown-Yellow-57 Brown-White-58 White-Orange-60 White-Beige-61 White-Blue-64 White-Grey-65 Orange-Grey-68 Pink-White-83 Beige-White-84 Red-Green-93 Red-Yellow-94 Beige-Red-91 Yellow-Black-96 Yellow-Brown-97 Yellow-Violet-99 Blue-White-A02 Green-Blue-A03 Green-White-A04 White-Yellow-A08 Violet-Red-A09 Green-Orange-A13 Blue-Orange-A14 Red-Violet-A22 Grey-Orange-A26 Blue-Grey-A34 Green-Violet-A35 Brown-Violet-A40 Pink-Violet-A41 Pink-LTGreen-A45 Green-LTGreen-A46 Green-LTBlue-A47 White-LTBlue-A49 Violet-LTGreen-A53 White-LTGreen-A55 Brown-LTBlue-A69 Brown-LTGreen-A71 LTGreen-Grey-A72 Blue-Yellow-32 White-Green-A07 Grey-LTBlue-A48 Red-Orange-25 Blue-Red-31 Blue-Green-33 Black-Brown -35 Grey-Red-47 Brown-Green-59 Orange-Brown-69 Orange-White-73 Pink-Blue-80 Orange-Green-71 Violet-Green-77 Pink-Orange-81 Yellow-Orange-98 Blue-Brown-A01 Grey-Yellow-A05 Violet-White-A11 Pink-Yellow-A15 Black-Grey-A16 Red-Blue-A17 Red-Grey-A18 Red-Pink-A19 Pink-Green-A20 Violet-Pink-A23 Red-Brown-A25 Grey-Brown-A39 Yellow-Grey-A43 LTGreen-Red-A44 LTBlue-Violet-A58 LTGreen-LTBlue-A59 Blue-LTBlue-A60 Brown-Beige-A62 Green-Beige-A63 Beige-A64 Blue-LTGreen-A67 Pink-LTBlue-A74 Beige-LTGreen-A75 Pink-Grey-A76 Red-LTGreen-A77 LT- Green/Dark-Green -A79 White-Pink -A80 Blue-Violet-A68 LTGreen-Green-A70 Blue-Tan-A83 Black-Green-37 Black-Red-39 LTGreen-Pink-A36 Brown-Pink-A84 Yellow-Red-95 Orange-Black-67 Blue-Black-30 White-Violet-A06 Grey-Black-49 Black-Violet-A78 Black- White-40 Black- Yellow-41 Red-Black-24 White-Red-66 White-Black-62 White-Brown-63 Red-White-A12 Beige-Brown-A87 LTGreen-Black-A95 Beige-Orange-89 Blue-Beige-A66 175 Siechem Wires & Cables Meet EU RoHS Directive AS 9100 ISO 45001 ISO 9001 ISO 14001 IATF 16949
